RFID Coverage
Endpoint counts from the drawing legend
560
Rack antennas
15
Autopsy antennas
2
Embalming antennas
26
RFID gates
20
Vehicle antennas
623
Total endpoints
· Counts from Thalheimer drawing 352/2026 · L12 · covering 5 cold rooms.
Reading the Drawing
Legend and conventions
- Magenta barsRFID antennas — racking, autopsy, embalming
- Red arrowsRFID gate installations (26 total)
- Green truckVehicle drop-off / pick-up lane
- Central gridCold rooms C · D · E (−20°C) and A · B (4°C)
- Left wingAutopsy suites · dissecting tables · embalming
Version L12 · submitted 27 February 2026 by Thalheimer Kühlung GmbH · installation by Modern Pharmaceutical Company.
